Key Features
- Strong Lifting Performance: Features a 4-section, 25.5m hexagonal cross-section boom, the longest in its class.
- New Energy-Saving Hydraulic System: Minimum stable slewing speed of 0.3°/s and minimum stable hoisting speed of 3.0m/min, allowing for precise and safe lifting operations.
- Optimized Power System: The upgraded diaphragm spring clutch improves torque transmission efficiency, and combined with a large ratio gearbox, the maximum gradeability can reach 35%.
- Intelligent Operation: Equipped with a color screen, providing rich machine information and a convenient human-machine interaction interface.
- Safe and Reliable: Has the most complete safety device system in the industry, ensuring safer and more reliable lifting operations.
Specifications
| Dimension | Unit | Value |
|---|---|---|
| Max. Rated Total Lifting Capacity | t | 8 |
| Max. Lifting Torque | kN.m | 302 |
| Overall Length | mm | 9375 |
| Overall Width | mm | 2400 |
| Overall Height | mm | 3240/3170 |
| Total Weight in Travel | kg | 12300/12100 |
| Max. Travel Speed | km/h | 90 |
| Min. Turning Diameter | m | 16 |
| Max. Gradeability | % | 35 |
| Fuel Consumption for 100km | L | 18 |
