Key Features
- Max. Lifting Capacity: 100 tons
- Main Boom: Eight-section “U-shaped” main boom, extending up to 82 meters.
- Outriggers: 8.1-meter H-type lateral outrigger span, providing high stability.
- Chassis: Five-axle, high-load truck crane chassis with three-axle drive and three-axle steering.
- Engine Rated Power: 316 kW (at 1900 r/min).
- Max. Travel Speed: 80 km/h (approx. 50 mph).
- Max. Gradeability: 45%.
The crane features a full rectangular frame structure for enhanced bearing capacity and is widely used in oilfields, mines, and general engineering projects such as urban renewal and construction sites.
Specifications
The QY100K8C is a high-performance 100-ton capacity truck crane designed for demanding lifting operations in various construction and industrial environments.
| Feature | Specification | |
|---|---|---|
| Max. Lifting Capacity | 100 tons (220,462 lbs, or 100,000 kg) | |
| Overall Length (Transport) | 49.97 ft (approx. 15.2 m) | |
| Overall Width (Transport) | 9.85 ft (approx. 3 m) | |
| Overall Height (Transport) | 12.67 ft (approx. 3.8 m) | |
| Total Weight (Travel) | ~55,000 kg (121,254 lbs) | |
| Max. Travel Speed | 80 km/h (approx. 50 mph) | |
| Max. Gradeability | 45% | |
| Min. Turning Diameter | 24 m |
Boom & Lifting System
The crane features a multi-section, U-shaped telescopic boom for extended reach and lifting height.
| Feature | Specification | |
|---|---|---|
| Max. Main Boom Length | 82 meters (approx. 269 ft) | |
| Number of Boom Sections | 8 (U-shaped) | |
| Max. Lifting Height (Boom only) | ~61.2 meters | |
| Jib Length (Fully extended) | Up to 19.5 meters (optional) | |
| Max. Lifting Height (Boom + Jib) | Up to 78 meters | |
| Outrigger Span (Lateral) | 8.1 meters (H-shaped) |
Engine & Power
The carrier is powered by a high-performance diesel engine suitable for heavy loads and challenging terrain.
| Feature | Specification | |
|---|---|---|
| Engine Rated Power | 316 kW (at 1900 r/min) or 434.5 hp (at 1800 rpm) | |
| Max Torque | 1548.9 lb ft | |
| Drive System | 5-axle chassis, 3-axle drive/steering |
