Key Features
- Efficient and Reliable: The L953H is equipped with a Weichai WP10H National IV engine, which provides strong power and high reliability.
- Flexible Operation: The machine has an appropriate wheelbase (3000 mm) and a small turning radius, balancing heavy-load performance with flexibility.
- Strong Working Performance: It features a dual-pump flow converging hydraulic system, offering fast lifting speeds and quick, powerful operation. The boom lifting time is only 5.7 seconds.
- Durable: It utilizes a strengthened bucket with strong wear resistance and is equipped with a Lingong planetary gearbox and strengthened drive axles to improve service life.
Specifications
| Parameter | Value |
|---|---|
| Rated Load | 5000 kg |
| Bucket Capacity | 2.8 m³ (optional 2.4-4.5 m³) |
| Rated Power | 162 kW |
| Dimensions (L×W×H) | 7920×3024×3423 mm |
| Wheelbase | 3000 mm |
| Min. Ground Clearance | 534 mm |
